Four Poles Solar Carport Mounting System

Four Poles Solar Carport Mounting System

The four poles carport is easy installed and save space which can be used for commerical and residential installation.

  • Brand:

    UISOLAR
  • Item NO.:

    UI-Pole Carport
  • Payment:

    T/T, L/C
  • Price:

    $0.08/watt
  • Product Origin:

    Fujian, China
  • Color:

    Silver
  • Shipping Port:

    Xiamen China
  • Lead Time:

    15 days
  • Product Details

Four Poles Solar Carport Mounting System

Solar panel poles carport mounting structure


solar car parking mount water proof carport



solar carport mount solution pole



 Item No

 UI-Four Poles Carport

 Installation Site

 Open Ground

 Material

 Q235 galvanized steel
6005-T5 aluminum

 Max Wind Speed

 60 m/s

 Warranty

 10 Years

 Max Snow Load

 1.4 KN/M2

 Service Life

 25 Years

 Panel Tilt Angle

 0-30 Degree



1. Matericials

Using Q235 galvanized steel and 6005-T5 aluminum,high-strength,well anti-corrosion.

2. Multi-functions

This solar carport with functions of parking, producing green power , waterproof, meeting different needs.

Waterproof Carport solar panel

3. Flexible Carport

Pole carport has more space and flexible for parking from every sides.

Carport solar panel pv large space parking




Alu test report for Mid clamp and end clamp AL6005-T5 Report



solar panel carport rack package




Solar panel poles carport mounting


We are China Carport solar mounting system company,supply Quality commercial solar carport mounting systems,best price!
